SW1 early switch
Fitted to early panels, they were illuminated, red, green and orange. These switches are no longer available, we carry a small stock of switches, or re-cycled so odd ones can be supplied, contact us for availability.
New switch set is available, these switches use a coloured flash, and are not
SW2 SPST small
Small on / off switch used on switch panels and helm panels.
There are a number of switches that were used, with various marking, these are no longer available, the replacements have no marking.
There are a number of switches that were used, with various marking, these are no longer available, the replacements have no marking.
SW3 SPDT small
This switch was used for marker lights on the small helm panel.
SW4 DC / AC switch
These switches were used on on later panels for DC switching ( green ) and AC switching ( white ).
SW5 Illuminated DC switch
Used on old type panels,
SW6 Non illuminated AC switch
Used mainly for AC switching, battery charger and water heater.
SW7 Push on / push off switch
Used on late model helm panels.
CB1 early circuit breaker
These were used for DC and AC circuits on early panels.
Late panels had a similar circuit breaker, but switchable, CB4, contact for availability
Late panels had a similar circuit breaker, but switchable, CB4, contact for availability
CB2 Otter circuit breaker
These were used on most switch panels for DC and AC switching. They can be identified by the front face being flush, the reset pad appear as touch pads, with a trip light in top right corner.
We have limited stock, but have an alternative in the pipe line to provide long term supply.
We have limited stock, but have an alternative in the pipe line to provide long term supply.
CB3 circuit breaker, 15 amp
These were used mainly for the AC supply on switch panels without RCD.
Early units had a circuit breaker design that is twice as wide, this breaker is now long out of production, we have a way of fitting this breaker, please contact for assistance.
Early units had a circuit breaker design that is twice as wide, this breaker is now long out of production, we have a way of fitting this breaker, please contact for assistance.
Replacement relay units, these two models will replace all Powercentre units supplied. They are not identical, but they are fully operation compatible. Early units may require the use of a adaptor cable, as the plugs originally used cannot be sourced for spares. The adaptors can also be used to allow a new plug to be grafted on to replace a damaged later type plug.
R2 twin relay
Twin battery bank split charge relay , replaces all the original Powercentre units .
Units require a RC6/6 connector cable for early type relays.
each unit 70 mm x 110 mm x 45 mm
used on Sealine and Westerly
Units require a RC6/6 connector cable for early type relays.
each unit 70 mm x 110 mm x 45 mm
used on Sealine and Westerly
R3 triple relay
Triple battery bank split charge relay , replaces all the original Powercentre units .
Units require a RC6/8 connector cable for early type relays.
each unit 70 mm x 110 mm x 45 mm
used on Sealine, Birchwood, Sunseeker, Fairline, Suncruiser
Units require a RC6/8 connector cable for early type relays.
each unit 70 mm x 110 mm x 45 mm
used on Sealine, Birchwood, Sunseeker, Fairline, Suncruiser
adapter cables RC4/6 .. 6 way, RC6/8 .. 8 way
Adapter cable, allows original Powercentre units to use later type connector socket.
The plugs used on original units are not available now.
Can also be used to replace a damaged later type plug, without changing complete harness.
The plugs used on original units are not available now.
Can also be used to replace a damaged later type plug, without changing complete harness.
shore / gen relay SG1 ..15 amp, SG2 30 A man, SG3 .. 30 A auto
Shore gen relays were used to switch mains between shore and on board generator.
SG1 is automatic, it also drove the supply status display, SG2 is manual operation and rated at 30 amp, SG3 is automatic operation, rated at 30 amp,
used on Sealine,
SG1 is automatic, it also drove the supply status display, SG2 is manual operation and rated at 30 amp, SG3 is automatic operation, rated at 30 amp,
used on Sealine,
PL1 power lock-out relay
Power lock-out relay, rated at 20 amp, replacement for original Powercentre unit.
It will require terminal changes to cables to fit new unit.
used on Sealine, Westerly
It will require terminal changes to cables to fit new unit.
used on Sealine, Westerly
Spare bar-drivers are available for all the units supplied by Powercentre. They employ the latest Kdd electronic shunts sensor heads, plus redesigned and updated electronics. They are a different shape, but have the same output profile, pin outs, and ratings as the original modules.
check your switch panel display for amp rating before ordering.
check your switch panel display for amp rating before ordering.
B2 dc early, B3 later 12 pin plug
Replaces bar-driver unit as used in generation 2 charge bar-graph / display systems.
70 mm x 110 mm x 45 mm
used on Sealine 328 So and 365 Sb.
used on Sealine 328 So and 365 Sb.
BR1 dc
Bar-driver and triple battery bank split charge relay set, replaces the original single unit as first fitted, brings system up to later specification.
Units are plug compatible, interface with display, no wiring modifications.
each unit 70 mm x 110 mm x 45 mm
used on Sealine 328 So and 365 Sb
each unit 70 mm x 110 mm x 45 mm
used on Sealine 328 So and 365 Sb
Sealine model type Am ... Ambassador, At .... Attache, En .... Envoy, Fl .... Flybridge,
Sb .... Sports bridge, Se .... Senator, So .... Soverign, Sp .... Sport, St .... Statesman,
Sb .... Sports bridge, Se .... Senator, So .... Soverign, Sp .... Sport, St .... Statesman,
AB1 ac no AC volts, AB4 amps and volts
Replacement for generation 1 AC bar-graph driver, does not include voltage converter.
70 mm x 110 mm x 45 mm
Used on Sealine AB1 450 St, AB4 420 St, 450 St, Marine Projects Riviera
Used on Sealine AB1 450 St, AB4 420 St, 450 St, Marine Projects Riviera
bar-driver / relay ac AB2 manual, AB3 automatic
Replacement for generation 2 AC bar-graph driver, includes voltage converter and automatically selected, 30 amp, two pole, shore / generator selector relay
140 mm x 160 mm x 80 mm
Used on Sealine 390 St, 410 St, 450 St
Used on Sealine 390 St, 410 St, 450 St
B4 dc 2 x 6 way plug, B5 1 x 12 way plug
Replacement bar-driver for g eneration 4 & 5 bar-graph / display system, twin 6 way plugs.
70 mm x 110 mm x 45 mm
B4/30.. 30 amp, B4/60 .. 60 amp unit check display for amp rating before ordering.
used on Sealine 230 Se, 240 Sp, 240 Se, 270 Se, 300 Am, 310 Am, 320 St, 360 Am,
360 St, 380 Am, 390 St, 400 Am, 410 St 420 St, 450 St Marine Projects ... Riviera
B4/30.. 30 amp, B4/60 .. 60 amp unit check display for amp rating before ordering.
used on Sealine 230 Se, 240 Sp, 240 Se, 270 Se, 300 Am, 310 Am, 320 St, 360 Am,
360 St, 380 Am, 390 St, 400 Am, 410 St 420 St, 450 St Marine Projects ... Riviera
CB5 circuit breaker
These were used on 390, 420, and 450 panels for DC and AC circuits, they indicate off.
Contact us for availability.
Contact us for availability.
