•  zero volt drop charge, relay sealed to IP66

•  programmed charge priority to all battery banks.

•  fixed charge voltage switching, alternate values can be supplied

•  no changes to engine wiring loom, suits all charge forms.

•  dual sensing / bi-directional charge

•  internal circuit protection to control, display,  relay drive circuits

VSR charge relays rating ( link start rating )

  80 amp continuous, surge current to 300 amps

100 amp continuous, ( to  250 amp start current, surge current to 400 amp* )

125 amp continuous, ( to  500 amp start current, surge current to 1200 amp* )

LS   emergency link-start

•  allows emergency engine starting from service battery, available with 100 amp and 125 amp VSR relays.

•  remote operation one minute timed on period, leaves both hands free for engine starting.

LVPR     low voltage power reserve

•  isolates non-critical service battery loads at pre-set low voltage ( user adjustable ) 4 minute lock-out delay.

•  relay rated at 80 amp continuous, 150 amp upto 4 minutes, relay sealed to IP66.

•  improves battery life by limiting excessive battery drain, and sulphation.

RCP    remote control panel

•  allows remote monitoring and operation of the LVPR system, visual plus audio alarm for operation, alarm mute,

   timed over-ride of power lock-out, manual system over-ride, manual power lock-out engagement, LED indication.

battery status display

•  remote bar-graph display provides, separate battery volts for each battery, high charge volt alarm drive.

•  amps charge / discharge with polarity for service battery, integral electronic shunt and voltage pick-up.

options

A number options are available, either factory fitted or customer fitted depending on item.

module size  250 mm x 125 mm x 75 mm   sizes are nominal, and will vary depending upon spec.

schmatic diagram

spec your VSR system

standard  features

4 core cable

* subject to correct sized cabling

P-3200

single or twin engines

two battery banks

integral ammeter shunt

bar-graph display

standard settings

•  relay cuts in at 13.8 volt,  relay drops out 13.0 volt,  other vales can be supplied to order.
